Phase Failure Relay MA51BC

Why order with Anymeters?

•     Fast Next-Day Delivery on stocked products you need quickly.
•     1PM Cut-Off for Same-Day Dispatch, clear timelines, no guesswork.
•     Free Delivery on Orders Over £500; added value for larger projects.
•     Hassle-Free Returns Process with quick pre-authorisation support.
•     Easy Damage Claims, notify us within 5 days with photos for swift help.

• Supply Voltage 415VAC
• Frequency 50/60 Hz
• Power Consumption (Max.) 15 VA
• Trip Settings Phase Loss Yes
• Trip Settings Phase Sequence Yes
• Trip Settings Phase Asymmetry 40 V (+/- 10 V)
• Trip Settings Hysteresis 10 to 8 V
• Time Delay - On Delay 2 s (+/- 2 s)
• Time Delay  - Trip Time (OFF Delay) 7 s (+/- 2 s)
• Output  - Relay Output 1 C/O
• Output - Contact Rating 5A (For `NO') & 3A (For `NC') @ 250 VAC / 28 VDC (Resistive)
• LED Indication Red - Relay ON (Healthy)
• Operating Temperature (-10deg to +50deg)
• Storage Temperature (-20deg to +65deg)
• Enclosure Flame Retardant UL 94 - V0
• Dimension ( W x H x D) ( in mm) 36 X 90 X 60
•  Weight (unpacked) 120g
• Mounting Base / DIN rail

MA51BC is designed to meet Industrial and Agricultural segment applications. No Auxiliary supply is needed and it also protects against Phase Loss, Phase Reversal and Phase Asymmetry.
