The MB5D Range of Solid Core Current Transformers from Crompton Instruments work in conjunction with any 5A CT Operated Electricity Meters. You can use individual MB5D CTs for Single Phase applications, you can also use several of these current transformers for Three Phase applications. The Aperture on this model accommodates 63mm² Cable, as well as 80mm x 30mm, 60mm x 30mm & 50mm x 50mm Busbar. The MB5D is ideal for applications such as Distribution systems, Generator sets, Control Panels and Switchgear.

Technical Specification

• 63mm² Aperture
• 80mm x 30mm Busbar Aperture
• 60mm x 30mm Busbar Aperture
• 50mm x 50mm Busbar Aperture
• 800-1600A Primary Current
• 5A Secondary Current
• Secondary M4 Screw Terminals
• Accuracy Class 0.5, 1 or 3
• Busbar or DIN Rail Mounted
