Smart Process & Control Ltd
Smart Process SDM230DR Single Phase Power Analyser
£35.00
Excluding VAT. Shipping calculated at checkout.
MID
Approved
Approved
Secure
Checkout
Checkout
Fast UK
Delivery
Delivery
Product Specifications
PRODUCT FEATURES
Overview
Why order with Anymeters?
- Fast Next-Day Delivery on stocked products you need quickly.
- 1PM Cut-Off for Same-Day Dispatch, clear timelines, no guesswork.
- Free Delivery on Orders Over £500; added value for larger projects.
- Hassle-Free Returns Process with quick pre-authorisation support.
- Easy Damage Claims, notify us within 5 days with photos for swift help.
All programming must be done before dispatch
SDM230DR is a basic digital single phase kWh energy meter, which measures up to 100A direct load. The unit measures Total Active Energy.This meter is very popular due to its cost effectiveness and simplicity of installation. This Series has been assessed and certified as meeting the requirements of EC Directive 2004/22/EC. The EC Type Examination Certificate Number is 0120/SGS0206.
Technical Specification
- MID B&D Approved - 0120/SGS0198
- Single Phase (1P2W)
- Displays Total Active Energy (kWh)
- 100A AC
- 230V AC
- Pulsed Output
- 2-DIN Module
- Digital Backlit Display
